Factory Price for Programmable Logic Controller PLC for Intelligent Control (Programmable Relay PR

Basic Info.

Model NO.	PR-18AC-R-HMI
Material	Fr-ABS
Outputs	6 Relays(10A)
Inputs	12 Digital
Transport Package	Standard Export Carton
Specification	CE, RoHs, SGS
Trademark	RIEVTECH
Origin	Nanjing, China
HS Code	8537101190
Production Capacity	1000PCS/Month

Product Description

Micro PLC PR-18 series (Expandable Range)series overview:
PR-18 range(Micro PLC) is advanced level model, incorporating a good mix of digital and Analogue IO, Integrated High Speed inputs and PWM output,clock with calendar, counters , timers , integrated keypad display, serial communications and an expansion port. Available in 120V/240VAC or 12V/24VDC versions ; Easy to configure with drag-and-drop function blocks or ladder using FREE xLogicSoft software. Program capacity has been enlarged to 512 function blocks as well, also high-speed count reaches 60KHZ. PR-18 range offers 4-line*16 characters LCD display and keypad for program modification or display and control whilst program is running. An expansion port allows the connection of up to 10 expansion modules, extending the I/O channel count. Now it is also possible to use the analog output module to solve simple closed-loop control tasks. Heating andcooling systems can be designed with the RTD PT100 module using special functions for PI control, ramp response and analog multiplexer.
Product Description:Highlight of PR-18 Series: ×55 ready-to use functions integrated-no additional devices such as operating hours counter required. ×Extremely large program capacity:up to 512 functions possible.×PR-18 series offers 4 line x16 characters LCD display and keypad for program modification or display and control whilst program is running.×12 digital inputs(incl 8AI with 12/24V DC)and 6 digital outputs on board. ×Flexibly expandable up to 92DI,86DO,36AI,and 18AO.×Display of message texts,actual and set-point values and direct modification of the values on the display(not on pure variants).×Integrated data retentivity-ensures backup of the current values in the event of a power failure.×Customizable Start-up page/screen.×Bool function,multiple timers,counters,PWM,PI controller,Ramp.Analog math supported. ×Can be modularly expanded up to 178 I/Os. ×230V units can be expanded with analog modules. ×Data-logging:Data from the production process can be saves in SD card of the external accessory called ELC-MEMORY to either read it with a PC or evaluate it from the SD card at the workstation.×Extremely simple software×Display of up to 64 messages.×Multiple kinds of registers can be accessed.×Parameters setting menu in LCD panel.×Parameters can be modified in the alarming message.×Modbus RTU/ASCII/TCP protocol supported.×Retentive memory capability.×Powerful communication capability(1RS232 port,1 RS485 port and 1 expansion port)×Password protection.×It's optional for xLogic to act as salve or master in certain Modbus communication network.×Backup at Real Time Clock(RTC) at 25 ºC:100hours.×2 PWM channels optional.×Communicate with third party device which supports Modbus network.
Technical Specifications:GENERAL SPECIFICATIONSTimers : 512Counters : 512Function Blocks : 512Operation temp. : -20ºC-55ºC Storage :-40ºC-70ºCProtection : IP20(Non-waterproof) RTC accuracy : MAX ±5S/dayRTC time intervals : 512RTC Backup at 25 °C : 100 hoursPower-off retentivity : yesModify parameters via keypad LCD: yesDimensions : 95*90*61(Unit:mm)Certificate : CEInstallation : 35-DIN rail or screw for installationExpansion capacity: 9 modules (PR-E-16, CAN BUS)Password protection : Multiple password protectionCommunication interface : TTL interface , 1 RS232 port & 1 RS485 portCommunication protocol : Modbus RTU/ASCIITechnical Index

Power supply
Power	AC110V-240V
Input parameters:
Input No	12 ( I1-IC )
Digital input	12 ( I1-IC )
Analogue input	None
Power range	AC 0-240V
Input signal0	AC 0-40V
Input signal1	AC79-240V
Output parameters:
Output No	6 (Q1-Q6)
Output type	Relay output
Continuous current	Resistive load 10A/Inductive load 2A
Switch frequency:
Mechanism	10Hz
Resistor/light load	2Hz
Sensitive load	0.5Hz
Other parameters:
The main frequency range	47-63Hz
Weight	Approx.350g

Dimensions & Wiring Diagram:
Dimensions:Wiring Diagram:
